3100B0250S02B Setra Pressure Transmitter 0-250 Bar
Product Information
SETRA 3100B0250S02B Is a High-Pressure Industrial Pressure Transmitter Designed For Reliable And Continuous Pressure Measurement. It Provides a 4–20 mA Output And is Suitable For OEM And Industrial Pressure-Monitoring Applications.The Compact 3100 Series Design Uses a Sputtered Thin-Film Sensing Element And Stainless-Steel Wetted Construction
Technical Data
- MANUFACTURER: SETRA
- Model: 3100B0250S02B
- Pressure Range: 0 to 250 Bar
- Pressure Type: Gauge
- Output Signal: 4–20 mA
- Supply Voltage: 8–30 VDC
- Pressure Connection: G 1/4-18 NPT Male
- Electrical Connection: DIN 43650 Form C
- Enclosure Protection: IP67
- Temperature Range: -40°C to +125°C
- Wetted Parts: Stainless Steel
- Series: SETRA 3100
- Approval: cURus
- RoHS Compliant
- Weight: Approximately 35 g
Product Features
- 0–250 Bar High-Pressure Measurement
- Stable 4–20 mA Industrial Output
- Sputtered Thin-Film Sensing Technology
- Compact OEM Design
- Stainless-Steel Wetted Parts
- IP67 Protection
- Wide Operating Temperature Range
- Suitable For Continuous Pressure Monitoring
Field of Application
- Hydraulic Systems
- Industrial Machinery
- Compressors
- Pumps
- Irrigation Systems
- Process Equipment
- Refrigeration Systems
- HVAC Equipment
- OEM Pressure Monitoring
- Gas and Fluid Pressure Measurement
Ambient Condition
The Transmitter is Designed For Industrial Environments With An Operating Temperature Range of Approximately -40°C to +125°C.IP67 Enclosure Protection Helps Protect The Transmitter Against Dust And Water Ingress
Material
The 3100 Series Uses Stainless-Steel Wetted Components For Compatibility With Demanding Industrial Pressure Applications
Electrical Data
Supply: 8–30 VDC
Output: 4–20 mA
Electrical Connection: DIN 43650 Form C
Installation Guide
Install The Transmitter On a Compatible 1/4″ NPT Pressure Connection. Ensure The Process Connection is Clean And Properly Sealed.Connect The DC Power Supply And 4–20 mA Signal According To The Applicable Wiring Configuration.Do Not Exceed The Specified Pressure Range.Protect The Electrical Connection From Moisture During Installation.
Approval
The Available Specification Lists cURus Approval And RoHS Compliance.
Accessories
- Compatible Pressure Fittings
- NPT Adapters
- Sealing Accessories
- Electrical Mating Connector
- Installation And Mounting Accessories
- Suitable 4–20 mA Control-System Wiring Accessories
Product Summary
SETRA 3100B0250S02B Pressure Transmitter Is a 0–250 Bar Industrial Pressure Transmitter With 4–20 mA Output, 8–30 VDC Supply, 1/4″ NPT Male Process Connection And IP67 Protection.It Is Suitable For Hydraulic, Industrial, OEM, Pump, Compressor And Process-Pressure Monitoring Applications.
