Series RHP Humidity Temperature Transmitter Wholesaler

Nov 3, 2021 by admin 0 Comments

RHP-2D10 DWYER Humidity Temperature Transmitter



Minimum Order Quantity12 Number
Model Name/NumberRHP-2D10
BrandDwyer USA
Voltage10~35 VDC
Accuracy2%
Usage/ApplicationIndustrial
Product Weight8.24 oz Gross Weight:1 lb
Protection TypeRHP-2D10 DWYER Humidity Temperature Transmitter
Part TypeRHP-2D10 DWYER Humidity Temperature Transmitter
SizeH x W x D:4 in x 4.4 in x 11.75 in
ItemRHP-2D10 DWYER Humidity Temperature Transmitter
Precautions For UseAir Economizers,Outdoor Temperature and Relative Humidity Reference,Pool Room Humidity Monitoring
Sensor Output4~20 mA
Humidity0 to 100% RH
Packaging Type1 NOS
Country of OriginMade in India


RHP-2D10 DWYER Humidity Temperature Transmitter

Overview

Dwyer Instruments

Humidity Sensors, RHP Series

  • Item# RHP-2D10 – Duct Mount Humid- Ity Transmitter Wtih 2% Sensor And 4-20 Ma Output


RHP Series Information

The Series RHP Temperature and Humidity Transmitter Combine the Voltage or Current Humidity Transmitter output with a passive Temperature Thermistor or RTD output. Featuring Polymer Capacitance Humidity Sensors, Models are available in 2%, 3% or 5% accuracies. Duct mounted transmitters are available with an optional two-line alpha numeric LCD Display.

Product Applications

  • Air Economizers
  • Outdoor Temperature and Relative Humidity Reference
  • Pool Room Humidity Monitoring


Specifications

  • Item Number:  RHP-2D10
  • Brand:Dwyer Instruments
  • Item Category:HVAC Sensors
  • Subcategory:Humidity Sensors
  • Series:RHP
  • Application:Duct
  • Input:10~35 VDC
  • Output:4~20 mA
  • Display:None
  • Humidity Range:0 to 100% RH
  • Temperature Sensor:No
  • Approvals:CE
  • Size:H x W x D:4 in x 4.4 in x 11.75 in
  • Net Weight:8.24 oz
  • Gross Weight:1 lb

RHP-2D1B DWYER Humidity Temperature Transmitter



Minimum Order Quantity12 Number
Model Name/NumberRHP-2D1B
BrandDWYER USA
Voltage4-20 mA
Accuracy2%
Usage/ApplicationIndustrial
Warranty1 YERS
ColorWHITE
ItemRHP-2D1B DWYER Humidity Temperature Transmitter

RHP-2D1B DWYER Humidity Temperature Transmitter

RHP-2D1B | Dwyer Instruments | Humidity

Relative Humidity, Passive Temperature Sensor Transmitter, 2%, Duct Mount with Plastic Hydrophobic Filter, 4-20 mA RH Output, 10K @ 25°C Thermistor Type II, No Options

  • Manufacturer:Dwyer Instruments
  • MPN:RHP-2D1B
  • SKU:RHP-2D1B

FAMILY DESCRIPTION

  • The Series RHP Temperature and Humidity Transmitter Combine The Voltage or Current Humidity Transmitter Output With a Passive Temperature Thermistor or RTD Output.The Polymer Capacitance Humidity Sensor is Not Affected By Condensation,Fog, High Humidity,or Contaminants.The Humidity Sensors Are Available With 2% or 3% accuracies.Duct Mounted Transmitters Are Available With an Optional Two-Line Alpha Numeric LCD Display.Application Note: For Duct Mount Installations,The Sintered Filter Option Should Be Ordered For Applications Where The Humidity Transmitter Is Mounted In The Supply Air Duct After The Fan And Cooling Coils.

  • ENVIRO TECH Description – 2% DUCT RH/TEMP XMITER 4-20MA 10K II

  • Manufacturer – Dwyer Instruments

PRODUCT APPLICATIONS

  • Air Economizers
  • Outdoor Temperature and Relative Humidity Reference
  • Pool Room Humidity Monitoring

PRODUCT HIGHLIGHTS

  • Duct Mount
  • 2% RH/Temperature Transmitter
  • 4-20 mA RH Output
  • 10K at 25 C Thermistor Temperature Output

PRODUCT FAMILY FEATURES

  • Robust Capacitance Humidity Sensor
  • Models With LCD Display
  • Interchangeable Filter And Replaceable Sensor Options


RHP-3D11 DWYER Humidity Temperature Transmitter



Minimum Order Quantity12 No
Model Name/NumberRHP-3D11
BrandDWYER USA
Voltage0-5/10V
Accuracy+-3%
Usage/ApplicationIndustrial
Warranty1 YEAR
Product WeightDuct mount: .616 lb (.3 kg); OSA: 1 lb (.45 kg).
Rated Supply Voltage0-5/10V
Response Time15 seconds.

RHP-3D11 DWYER Humidity Temperature Transmitter

The Series RHP Temperature and Humidity Transmitter combine the Voltage or current Humidity Transmitter output with a passive temperature thermistor or RTD output. The polymer capacitance humidity sensor is not affected by condensation, fog, high humidity, or contaminants. The humidity sensors are available with 2% or 3% accuracies. Duct mounted transmitters are available with an optional two-line alpha numeric LCD display. Application Note: For duct mount installations, the sintered filter option should be ordered for applications where the Humidity Transmitter is mounted in the supply air duct after the fan and cooling coils.
Availability: Item ships in about Ships in 4-6 weeks
Product Highlights

  • Duct mount
  • 3% RH/temperature transmitter
  • 4-20 mA RH output
  • 4-20 mA temperature output
OTHER CONFIGURATIONS AVAILABLE
PRODUCT SPECIFICATIONS
  • Relative Humidity Range: 0 to 100% RH.
  • Temperature Range: -40 to 140°F (-40 to 60°C).
  • Accuracy, RH: RHP-2XXX ±2% 10-90% RH @ 25°C; RHP-3XXX ±3% 20-80% RH @ 25°C; RHP-5XXX ±5% 20-80% RH @ 25°C.
  • Accuracy, Thermistor Temp Sensor: ±0.2°C @ 25°C (±0.36°F @ 77°F).
  • Accuracy, RTD Temp Sensor: DIN Class B; ±0.3°C @ 0°C (±0.54°F @ 32°F).
  • Hysteresis: ±1%.
  • Repeatability: ±0.1% typical.
  • Temperature Limits: -40 to 140°F (-40 to 60°C).
  • Storage Temperature: -40 to 176°F (-40 to 80°C).
  • Compensated Temperature Range: -4 to 140°F (-20 to 60°C).
  • 4-20 mA Loop Powered Models: Power Requirements: 10-35 VDC. Output Signal: 4-20 mA.
  • 0-5/10V Output Models: Power Requirements: 15-35 VDC or 15-29 VAC. Output Signal: 0-10V @ 5 mA max.
  • Response Time: 15 seconds.
  • Electrical Connections: Removable screw terminal block.
  • Conduit Connection: Duct Mount: 1/2″ NPS; OSA: 1/2″ (22.3 mm).
  • Drift: <1% RH/year.
  • RH Sensor: Capacitance polymer.
  • Temperature Sensor:
Types 1, 2, 3: Solid state band gap;
Curves A,B,C; Thermistor;
Curves D,E; Platinum RTD DIN 385. (See R-T Lookup Table).
  • Enclosure: Duct Mount: PBT; OSA: Polycarbonate.
  • Enclosure Rating: NEMA 4X (IP65) for OSA mount only.
  • Display: Duct Mount only, Optional 2-line alpha numeric, 8 characters/line.
  • Display Resolution: RH: 0.1%; 0.1°F (0.1°C).


RHP-3S22 DWYER Humidity Temperature Transmitter



Minimum Order Quantity12 No
Usage/ApplicationFor Outdoor Temperature and Relative Humidity Reference, Pool Room Humidity Monitoring
Model Name/NumberRHP-3S22
BrandDWYER USA
Voltage15 – 35 VDC or 15 – 29 VAC
Accuracy3%
WarrantyYAS
Output Type0 – 10 V (RH); 0 – 10 V (Temperature)
Size5-1/8″ x 2-1/4″ x 6-25/32″

RHP-3S22 DWYER Humidity Temperature Transmitter


  • RHP-3S22 – DWYER HUMIDITY/TEMPERATURE TRANSMITTER, OUTSIDE AIR WITH SINTERED FILTER, 0-10V RH & TEMP

DESCRIPTION


The Series RHP Temperature and Humidity Transmitter combine the Voltage or Current Humidity Transmitter output with a Passive Temperature Thermistor or RTD output. The polymer capacitance Humidity Sensor is Not Affected by Condensation, Fog,High Humidity, or Contaminants.

• Housing Design – Outside Air With Sintered Filter

PRODUCTS INFORMATION




  • MANUFACTURER:Dwyer
  • PART NUMBER:RHP-3S22
  • SHORT DESCRIPTION:RHP-3S22 – Humidity/Temperature Transmitter, 3%, Outside Air with Sintered Filter, 0-10V RH and Temperature Output
  • PRODUCT SERIES:Dwyer RHP Series Humidity/Temperature Transmitter
  • TEMPERATURE TYPE:Humidity/Temperature Sensors
  • SENSOR TYPE:Outdoor Sensor
  • ACCURACY:3%
  • RELATIVE HUMIDITY RANGE:0 to 100%
  • ACCURACY (TEMP):+/-0.2°C at 25°C
  • CONNECTION:Conduit Connection: 1/2″ NPS; Electrical Connection: Removable Screw Terminal Block
  • OUTPUT(S):0 – 10 V (RH); 0 – 10 V (Temperature)
  • VOLTAGE:15 – 35 VDC or 15 – 29 VAC
  • MAX TEMPERATURE:-40 to 140
  • CONSTRUCTION:Polycarbonate Housing
  • HOUSING TYPE:RHP Series OSA w/Sintered Filter
  • STANDARDS/APPROVALS:CE Approved
  • DIMENSIONS:5-1/8″ x 2-1/4″ x 6-25/32″
  • ADDITIONAL PRODUCTS OR REQUIREMENTS:Related Items: A-452, A-453, RHRS
  • USED WITH:Air Handling Economizers
  • APPLICATIONS:For Outdoor Temperature and Relative Humidity Reference, Pool Room Humidity Monitoring


RHP-2D22 DWYER Humidity Temperature Transmitter



Minimum Order Quantity12 No
Usage/ApplicationFor Outdoor Temperature and Relative Humidity Reference, Pool Room Humidity Monitoring
Model Name/NumberRHP-2D22
BrandDWYER USA
Voltage15 – 35 VDC or 15 – 29 VAC
Accuracy2%
WarrantyYAS
Output Type0 – 10 V (RH); 0 – 10 V (Temperature)
Size3-7/16″ x 11.59″

RHP-2D22 DWYER Humidity Temperature Transmitter

  • RHP-2D22 – DWYER HUMIDITY/TEMPERATURE TRANSMITTER, OUTSIDE AIR WITH SINTERED FILTER, 0-10V RH & TEMP

DESCRIPTION

The Series RHP Temperature and Humidity Transmitter Combine The Voltage or Current Humidity Transmitter Output With a Passive Temperature Thermistor or RTD Output. The polymer capacitance Humidity Sensor is Not Affected by Condensation, Fog,High Humidity, or Contaminants.
• Housing Design – Outside Air With Sintered Filter

PRODUCTS INFORMATION
  • MANUFACTURER:Dwyer
  • PART NUMBER:RHP-2D22
  • SHORT DESCRIPTION:RHP-2D22 – Humidity/Temperature Transmitter, 3%, Outside Air with Sintered Filter, 0-10V RH and Temperature Output
  • PRODUCT SERIES:Dwyer RHP Series Humidity/Temperature Transmitter
  • TEMPERATURE TYPE:Humidity/Temperature Sensors
  • SENSOR TYPE:Outdoor Sensor
  • ACCURACY:2%
  • RELATIVE HUMIDITY RANGE:0 to 100%
  • ACCURACY (TEMP):+/-0.2°C at 25°C
  • CONNECTION:Conduit Connection: 1/2″ NPS; Electrical Connection: Removable Screw Terminal Block
  • OUTPUT(S):0 – 10 V (RH); 0 – 10 V (Temperature)
  • VOLTAGE:15 – 35 VDC or 15 – 29 VAC
  • MAX TEMPERATURE:-40 to 140
  • CONSTRUCTION:PBT Housing
  • HOUSING TYPE:RHP Series Duct Mount w/Membrane Filter
  • STANDARDS/APPROVALS:CE Approved
  • DIMENSIONS:3-7/16″ x 11.59″
  • ADDITIONAL PRODUCTS OR REQUIREMENTS:Related Items: A-452, A-453, RHRS
  • USED WITH:Air Handling Economizers
  • APPLICATIONS:For Outdoor Temperature and Relative Humidity Reference, Pool Room Humidity Monitoring

RHP-3O22 DWYER Humidity Temperature Transmitter



Minimum Order Quantity12 No
Usage/ApplicationFor Outdoor Temperature and Relative Humidity Reference, Pool Room Humidity Monitoring
Model Name/NumberRHP-3O22
BrandDWYER USA
Voltage15 – 35 VDC or 15 – 29 VAC
Accuracy3%
WarrantyYAS
Temperature Range-40 to 140 DegreeF
Output Type0 – 10 V (RH), 0 – 10 V (Temperature)
Part TypeDWYER Humidity Temperature Transmitter
Size5-1/8″ x 2-15/64″ x 6-25/32″
ItemNEW
Temp Range-40 to 140 DegreeF
Humidity0 – 100%
Packaging Type1

RHP-3O22 DWYER Humidity Temperature Transmitter
  • RHP-3O22 – DWYER HUMIDITY/TEMPERATURE TRANSMITTER, 3%, OSA (OUTSIDE AIR)

DESCRIPTION

The Series RHP Temperature and Humidity Transmitter Combine The Voltage or Current Humidity Transmitter Output With a Passive Temperature Thermistor or RTD output. The Polymer Capacitance Humidity Sensor is Not Affected By Condensation, Fog, High Humidity, Or Contaminants.
• Housing Design – Outside Air


PRODUCTS INFORMATION

  • MANUFACTURER:Dwyer
  • PART NUMBER:RHP-3O22
  • SHORT DESCRIPTION:RHP-3O22 – Humidity/Temperature Transmitter, 3%, OSA (Outside Air), 0-10V RH and 0-10V Temperature Output
  • PRODUCT SERIES:Dwyer RHP Series Humidity/Temperature Transmitter
  • TEMPERATURE TYPE:Humidity/Temperature Sensors
  • ACCURACY:3%
  • RELATIVE HUMIDITY RANGE:0 – 100%
  • ACCURACY (TEMP):+/-0.2°C at 25°C
  • CONNECTION:Electrical Connection: Removable Screw Terminal Block, Conduit Connection: 1/2″
  • OUTPUT(S):0 – 10 V (RH), 0 – 10 V (Temperature)
  • VOLTAGE:15 – 35 VDC or 15 – 29 VAC
  • MAX TEMPERATURE:-40 to 140°F
  • CONSTRUCTION:Polycarbonate
  • MOUNTING OPTIONS:OSA (Outside Air)
  • HOUSING TYPE:RHP Series OSA (Outside Air)
  • STANDARDS/APPROVALS:CE Approved
  • DIMENSIONS:5-1/8″ x 2-15/64″ x 6-25/32″
  • ADDITIONAL PRODUCTS OR REQUIREMENTS:Related Items: A-452, A-453, RHRS
  • APPLICATIONS:For Air Economizers, Outdoor Temperature and Relative Humidity Reference, Pool Room Humidity Monitoring


DWYER Series RHP Humidity Temperature Transmitter



Minimum Order Quantity12 No
Model Name/NumberDWYER Series RHP
BrandDWYER USA
Accuracy2%, 3% or 5%
Usage/ApplicationIndustrial
WarrantyYAS
Part TypeDWYER Series RHP
ItemNEW
Packaging Type1

Series RHP Humidity/Temperature Transmitter

Passive Temperature Outputs, Sintered Filter Options

The Series RHP Temperature and Humidity Transmitter combine the voltage or current humidity transmitter output with a passive temperature thermistor or RTD output. Featuring polymer capacitance humidity sensors, models are available in 2%, 3% or 5% accuracies. Duct mounted transmitters are available with an optional two-line alpha numeric LCD display.

Product Applications

Air Economizers,Outdoor Temperature and Relative Humidity Reference,Pool Room Humidity Monitoring

Model        Description

  • RHP-2D10:Duct mount 2% RH transmitter with 4-20 mA RH output.
  • RHP-2D11:Duct mount 2% RH/temperature transmitter with 4-20 mA RH output and 4-20 mA temperature output.
  • RHP-2D11-LCD:Duct mount 2% RH/temperature transmitter, 4-20 mA RH output and 4-20 mA temperature output, with LCD.
  • RHP-2D1A:Duct mount 2% RH/temperature transmitter with 4-20 mA RH output and 10K Curve A passive temperature output.
  • RHP-2D1B:Duct mount 2% RH/temperature transmitter with 4-20 mA RH output and 10K @ 25°C thermistor temperature output.
  • RHP-2D1D:Duct mount 2% RH/temperature transmitter with 4-20 mA RH output and 100 Ohm RTD Curve D passive temperature output.
  • RHP-2D1E:Duct mount 2% RH/temperature transmitter with 4-20 mA RH output and 1K Ohm RTD DIN 385 temperature output.
  • RHP-2D1F:Duct mount 2% RH/temperature transmitter with 4-20 mA RH output and 20K NTC thermistor temperature output.
  • RHP-2D20:Duct mount 2% RH transmitter with 0-10 VDC RH output.
  • RHP-2D22:Duct mount 2% RH/temperature transmitter with 0-10 VDC RH output and 0-10 VDC temperature output.
  • RHP-2D22-LCD:Duct mount 2% RH/temperature transmitter, 0-10 VDC RH output and 0-10 VDC temperature output, with LCD.
  • RHP-2D2A:Duct mount 2% RH/temperature transmitter with 0-10 VDC RH output and 10K Curve A passive temperature output.
  • RHP-2D2B:Duct mount 2% RH/temperature transmitter with 0-10 VDC RH output and 10K @ 25°C thermistor temperature output.
  • RHP-2D2D:Duct mount 2% RH/temperature transmitter with 0-10 VDC RH output and 100 Ohm RTD Curve D passive temperature output.
  • RHP-2D2E:Duct mount 2% RH/temperature transmitter with 0-10 VDC RH output and 1K Ohm RTD DIN 385 temperature output.
  • RHP-2D2F:Duct mount 2% RH/temperature transmitter with 0-10 VDC RH output and 20K NTC thermistor temperature output.
  • RHP-2M11:Sintered filter duct mount humidity/temperature transmitter with 2% sensor, 4 to 20 mA output for humidity and temperature.
  • RHP-2M22:Sintered filter duct mount humidity/temperature transmitter with 2% sensor, 0 to 10 V output for humidity and temperature.
  • RHP-2O10:OSA 2% RH transmitter with 4-20 mA RH output.
  • RHP-2O11:OSA 2% RH/temperature transmitter with 4-20 mA RH output and 4-20 mA temperature output.
  • RHP-2O1A:OSA mount 2% RH/temperature transmitter with 4-20 mA RH output and 10K type III NTC thermistor temperature output.
  • RHP-2O1B:OSA mount 2% RH/temperature transmitter with 4-20 mA RH output and 10K type II NTC thermistor temperature output.
  • RHP-2O1D:OSA mount 2% RH/temperature transmitter with 4-20 mA RH output and Pt100 RTD temperature output.
  • RHP-2O1E:OSA mount 2% RH/temperature transmitter with 4-20 mA RH output and Pt1000 RTD temperature output.
  • RHP-2O1F:OSA mount 2% RH/temperature transmitter with 4-20 mA RH output and 20K NTC thermistor temperature output.
  • RHP-2O20:OSA 2% RH transmitter with 0-10 VDC RH output.
