Setra 3100B0160S01B Pressure Transmitter 0-160 Bar
Product Information
Setra 3100B0160S01B is an Industrial OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Gauge Pressure Up to 160 Bar. It Uses a Sputtered Thin-Film Sensing Element With Rugged Stainless-Steel Construction And is Suitable For Demanding Industrial Pressure Monitoring Applications.
Technical Data
- Model: 3100B0160S01B
- Brand: Setra
- Series: Model 3100
- Pressure Range: 0–160 Bar
- Pressure Type: Gauge
- Accuracy: ±0.25% FS
- Output Signal: 4–20 mA
- Supply Voltage: 8–30 VDC
- Electrical Connection: DIN 43650 Form C
- Process Connection: G1/4 / 1/4-18 NPT Male
- Enclosure Rating: IP67
- Operating Temperature: -40°C to +125°C (-40°F to +257°F)
- Wetted Construction: Stainless Steel
- Sensor Technology: Sputtered Thin Film
- Construction: All-welded stainless steel
- Pressure Media: Compatible Liquids And Gases,Subject To Wetted-Material Compatibility
- Pressure Range Code: 0160
- Protection: Reverse wiring protection
- Compliance: RoHS compliant
- Approvals: cURus
- Design: Compact OEM Industrial Pressure Transmitter
- Application Type: Continuous Pressure Measurement And Control
Product Features
• High Accuracy ±0.25% FS
• 0–160 Bar Pressure Measurement
• Stable 4–20 mA Industrial Output
• Wide 8–30 VDC Supply Range
• Rugged Stainless-Steel Construction
• IP67 Environmental Protection
• Compact OEM Design
• Reliable Performance Under Vibration And Industrial Conditions
• Suitable For High-Volume Industrial Applications
Field of Application
Hydraulic Systems,Industrial Machinery,Compressors,Pumps,Refrigeration Systems,HVAC/R Equipment,Process Monitoring,Irrigation Systems,OEM Equipment,Pressure Control Panels And Industrial Automation
Ambient Condition
Operating Temperature: -40°C to +125°C. IP67 Protection Helps Protect Against Dust And Water Ingress When Correctly Installed.
Material
Stainless-Steel Wetted Construction Suitable For Demanding Industrial Environments.
Electrical Data
- Input: 8–30 VDC.
- Output: 4–20 mA. DIN 43650 Form C Electrical Connection.
Installation Guide
Install on a Compatible Pressure Port Using The Correct Sealing Method. Ensure Pressure,Electrical Supply And Wiring Match The Transmitter Specifications.Avoid Excessive Mechanical Stress And Pressure Spikes. Verify Zero/Output Signal After Installation.
Approval
cURus and RoHS Compliant Configuration.
Accessories
Compatible Process Adapters,Sealing Accessories,Electrical Mating Connector,Pressure Tubing/Fittings And Calibration Equipment Can Be Supplied As Required.
