Setra 3100B0300S01B Pressure Transmitter 0-300 Bar

Oct 9, 2026 Setra Model 3100 and 3200 Pressure Transducers Wholesaler
www.envirotechdelhi.net

Setra 3100B0300S01B Pressure Transmitter 0-300 Bar


Product Information


Setra Model 3100B0300S01B Is An Industrial Pressure Transmitter Designed For Accurate Pressure Monitoring In OEM Machinery,Hydraulic Systems,Pumps And Industrial Process Applications.


Technical Data

  • Brand: Setra
  • Model: 3100B0300S01B
  • Measurement Range: 0–300 Bar
  • Output Signal: 4–20 mA
  • Supply Voltage: 8–30 VDC
  • Accuracy: ±0.25% FS (series specification)
  • Operating Temperature: -40°C to +125°C
  • Protection Rating: IP67
  • Pressure Connection: G1/4 / 1/4-18 NPT Male,Verify Exact Variant
  • Sensing Technology: Sputtered Thin Film
  • Wetted Parts: Stainless Steel
  • Response Time: 1 ms (Series Specification)
  • Electrical Connection: As Per Ordered Configuration
  • Pressure Type: Gauge
  • Mounting: Direct Pressure-Port Installation
  • Product Type: Industrial OEM Pressure Transmitter


Product Features

  • Compact And Robust Construction
  • Stable And Reliable Pressure Measurement
  • Stainless-Steel Wetted Components
  • High Resistance To Vibration And Demanding Environments
  • Reverse-Wiring Protection
  • Multiple Electrical Connection And Output Options
  • Designed For Continuous Industrial Monitoring


Field of Application


Hydraulic Power Packs,Industrial Pumps,Compressors,Booster Pump Systems,Irrigation Equipment,Process Automation,Industrial Machinery, Water Treatment Plants,OEM Equipment and Pressure Monitoring Systems.


Ambient Condition


Suitable For Industrial Environments Within The Specified Operating Temperature And Pressure Limits.Avoid Exceeding The Rated Pressure Or Environmental Limits.


Material


Stainless-Steel Wetted Components,Including a 17-4PH Stainless-Steel Diaphragm And 304 Stainless-Steel Fittings As Specified For The Model 3100 Series


Electrical Data


4–20 mA Current Output; 8–30 VDC Supply. Confirm Wiring,Connector And Pin Configuration Before Installation


Installation Guide


Install Using The Correct Pressure-Port Thread And Compatible Sealing Method.Ensure The System Is Depressurized Before Installation.Connect Power And Signal Wires According To The Manufacturer’s Wiring Diagram And Check For Leakage.


Approval


Series Documentation Specifies Applicable CE/UL And RoHS Compliance. Confirm Approvals For The Exact Ordered Variant.


Accessories


Compatible Electrical Connectors,Mating Cables,Pressure Fittings And Sealing Accessories,Subject To Model Configuration

Supplier: Enviro Tech Industrial Products,Delhi,India.Contact us for price, availability and technical Assistance.
