Setra 3100T200PG1G9 Pressure Transmitter 0-200 PSI
Product Information
Setra 3100T200PG1G9 is an industrial pressure transmitter designed for accurate and reliable measurement of pressure up to 200 PSI. It is suitable for industrial machinery, process control, hydraulic and pneumatic systems, compressors, pumps, OEM equipment and automation applications.
Technical Data
- Brand:SETRA
- Model:3100T200PG1G9
- Pressure Range:0–200 PSI
- Pressure Type:Gauge Pressure
- Output Signal:0.5–4.5 VDC
- Supply Voltage:8–30 VDC
- Accuracy:±0.25%
- Enclosure Protection:IP67
- Pressure Connection:1/4″ NPT Male
- Electrical Connection:Model/Configuration Dependent
- Operating Temperature:-40 to +125°C
- Construction:Compact, Rugged Stainless-Steel Design
- Compliance:RoHS Compliant
- Mounting:Direct Pressure-Line Installation
- Weight:Approx. 200 g.
Product Features
- 0–200 PSI pressure measurement range
- Reliable and accurate pressure monitoring
- Compact and robust industrial construction
- Suitable for continuous pressure measurement
- Easy integration with control systems
- Suitable for PLC,DCS, controllers and indicators
- Ideal for OEM and Industrial Machinery
- Suitable for process automation applications
- Reliable performance in industrial environments
Field Of Application
Industrial Process Control,Hydraulic Systems,Pneumatic Systems,Air compressors,Pumps,HVAC equipment,Industrial Machinery,Manufacturing plants,OEM equipment,Process Automation, instrumentation,Water Treatment,Chemical Processing,Pharmaceutical equipment,Food Processing,Packaging Machinery and General Pressure Monitoring
Ambient Condition
Install and operate within the manufacturer specified temperature, pressure and environmental limits. Protect the transmitter from excessive vibration,Shock,Moisture,Corrosive chemicals and conditions outside its rated specifications.
Material
Industrial-grade construction. Wetted and housing materials depend on the exact transmitter configuration.Verify the manufacturer Specification For compatibility with the process medium
Electrical Data
Power Supply,Output Signal And Electrical Connection Are According To the specific 3100T200PG1G9 configuration. Follow the manufacturer’s wiring diagram and verify the nameplate before electrical connection.Proper Grounding and suitable signal wiring are recommended
Installation Guide
- Isolate and depressurize the process line
- Install using the correct process connection and sealing method
- Avoid excessive mechanical force
- Connect wiring according to the manufacturer’s diagram
- Apply the correct power supply
- Check process and electrical connections
- Slowly apply pressure and check for leakage
- Verify the output signal and connect to the PLC/DCS/controller
Approval
Approval And Certification Depend On The Exact Product Configuration. Verify The Transmitter Nameplate And Official Manufacturer Documentation For Applicable Certifications Before Installation
Accessories
Pressure Fittings,Adapters,Seals,Electrical Connectors,Cables,Mounting Accessories,Pressure Tubing,Digital Indicators,PLC/DCS Interfaces, Isolation Valves And Calibration Equipment
