Setra Model3100B0016G01B is a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–16 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0016G01B
Pressure Range: 0–16 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Media: Compatible Gases And Liquids,Subject To Wetted-Material Compatibility
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 20 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–16 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements.
Setra Model3100B0040G01B is a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–40 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0040G01B
Pressure Range: 0–40 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Media: Compatible Gases And Liquids,Subject To Wetted-Material Compatibility
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 20 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–40 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements
SETRA Model 3100 Is a Compact OEM Industrial Pressure Transmitter Designed For Accurate And Reliable Measurement of Gauge Pressure.Part No.3100S0007G02B is Specified For a 0 to 7 Bar Pressure Range.The Model 3100 Uses Sputtered Thin-Film Sensing Technology And Rugged Welded Stainless-Steel Construction For Demanding Industrial Applications Technical Data
Model:SETRA 3100
Part No:3100S0007G02B
Pressure Range:0 to 7 Bar
Supply:8-32 VDC
OUTPUT:4…20 MA
CONNECTION:1/4″ NPT 304 SS
Pressure Type:Gauge
Accuracy:±0.25% FS
Response Time:1 ms
Enclosure Protection:IP67
Wetted Parts:17-4PH SS Diaphragm,304 SS Fittings
Operating/Storage Temperature:-40°C to +125°C
Compensated Temperature Range:-40°C to +125°C
Long-Term Stability:±0.2% FS For Ranges Below 60 Bar
Construction:All-Welded SS
Weight:Approximately 35 g
Product Features
High Accuracy And Repeatability
Sputtered Thin-Film Sensing Technology
Compact Design,Less Than 1 Inch Diameter
Rugged SS Construction
IP67 Environmental Protection
Excellent Vibration And Shock Resistance
Reverse Wiring Protection
Fast 1 ms Response Time
Suitable for OEM And Industrial Equipment
Field of Application
Hydraulic Systems
Industrial Machinery
Booster Pump Systems
Water And Irrigation Systems
Process Equipment
Compressors
HVAC And Industrial Automation
Power Generation Equipment
Mobile And Off-Highway Machinery
Pressure Monitoring And Control Systems
Ambient Condition
The Transmitter is Designed For Operation And Storage From-40°C to +125°C.Its IP67 Enclosure Provides Protection Against Dust And Temporary Water Exposure When Correctly Installed Material
The Pressure Sensing Diaphragm is 17-4PH SS,With 304 SS Fittings.The All-Welded SS Construction Provides Durability For Industrial Environments Electrical Data
The Model 3100 Family is Available With Multiple Electrical Output Configurations,Including 4–20 mA,1–6 VDC,1–5 VDC,0.5–4.5 VDC,0–5 VDC and 0–10 VDC,Depending On The Configured Part Number.The Exact Electrical Output And Connection Should Be Verified Against The Complete Ordering Code Before Installation.For 0–7 Bar versions,Setra Specifies That 0–10 V Output is Not Available Below 7 Bar Installation Guide
Verify The Pressure Range,Output And Pressure Connection Before Installation
Install The Transmitter Using The Correct Compatible Pressure Fitting
Do Not Exceed The Rated Pressure Range
Connect The Electrical Wiring According To The Applicable Setra Wiring Diagram
Protect The Cable/Connector From Excessive Moisture,Mechanical Damage And Contamination
Check For Leakage And Verify The Output Signal After Installation
Approval
Model 3100 is CE And UL Approved and RoHS Compliant,With IP67 protection Accessories
Setra Model3100B0020G01Bis a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–20 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0020G01B
Pressure Range: 0–20 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 20 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–20 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements
The Setra 3100B0070G02B Pressure Transmitter is Designed For Industrial Pressure Measurement And Monitoring Applications.It Converts Applied Pressure Into An Electrical Signal For Use In Automation,Process Control And Monitoring Systems.Its Compact Design Makes It Suitable For Installation In Industrial Equipment And Machinery Technical Data
Brand: Setra Systems
Model: 3100B0070G02B
Product Type: Pressure Transmitter
Pressure Range: 0–70 Bar
Supply Voltage: 8–30 VDC
Pressure Connection: 1/4″-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Protection: IP67
Operating Temperature: −40°C to +125°C
Wetted Material: Stainless Steel
Weight: Approximately 35 g
Output Signal: 4–20 mA
Accuracy: ±0.25% FS
Product Features
Reliable Industrial Pressure Monitoring
Compact And Durable Construction
Designed For Continuous Pressure Measurement
Suitable For Industrial Automation Systems
Easy Integration With Compatible Control Equipment
Suitable For Machinery And Process Monitoring
0–70 Bar Pressure Measurement Range
Field of Application
Industrial Process Control
Hydraulic Systems
Pneumatic Equipment
Industrial Compressors
Pump And Motor Systems
Water Treatment Plants
HVAC Systems
Manufacturing Machinery
Pressure Monitoring Systems
Industrial Automation
Ambient Conditions
Operating Temperature: Refer To The Exact Model Datasheet
Storage Temperature: Refer To The Manufacturer Specifications
Environmental Conditions: Suitable For Installation Within The Specified Operating Limits
Installation Location:Industrial Environments,Subject To Model Specifications
Material
Housing: 304 Stainless Steel
Wetted Parts: Stainless Steel
Sensing Element: Sputtered Thin Film
Robust Industrial Construction.
Electrical Data
Electrical Output: 4–20 mA
Supply Voltage: 8–30 VDC
Electrical Connection: G1/4,as Listed For This Model
Signal Compatibility: Compatible With The Corresponding Industrial Control System When Correctly Specified
Installation Guide
Verify That The Operating Pressure Does Not Exceed The Transmitter Specified Range
Ensure That The Process Connection Matches The Installation Port
Install The Transmitter Securely Using The Specified Fitting
Connect The Electrical Wiring According To The Manufacturer Wiring Diagram
Check The Power Supply And Output Compatibility
Inspect The Installation For Pressure Leaks
Verify The Output Signal Before Commissioning
Approval
Manufacturer Certifications,Electrical Approvals And Compliance Details Should Be Verified Against The Official Datasheet For Model 3100B0070G02B Accessories
The Setra 3100B0030G01B Pressure Transmitter is Designed For Industrial Pressure Measurement And Monitoring Applications.It Converts Applied Pressure Into An Electrical Signal For Use In Automation,Process Control And Monitoring Systems.Its Compact Design Makes It Suitable For Installation In Industrial Equipment And Machinery Technical Data
Brand: Setra Systems
Model: 3100B0030G01B
Product Type: Pressure Transmitter
Pressure Range: 0–30 Bar
Supply Voltage: 8–30 VDC
Pressure Connection: G1/4
Electrical Connection: DIN 43650 Form C
Enclosure Protection: IP67
Operating Temperature: −40°C to +125°C
Wetted Material: Stainless Steel
Weight: Approximately 35 g
Output Signal: 4–20 mA
Accuracy: ±0.25% FS
Product Features
Reliable Industrial Pressure Monitoring
Compact And Durable Construction
Designed For Continuous Pressure Measurement
Suitable For Industrial Automation Systems
Easy Integration With Compatible Control Equipment
Suitable For Machinery And Process Monitoring
0–30 Bar Pressure Measurement Range
Field of Application
Industrial Process Control
Hydraulic Systems
Pneumatic Equipment
Industrial Compressors
Pump And Motor Systems
Water Treatment Plants
HVAC Systems
Manufacturing Machinery
Pressure Monitoring Systems
Industrial Automation
Ambient Conditions
Operating Temperature: Refer To The Exact Model Datasheet
Storage Temperature: Refer To The Manufacturer Specifications
Environmental Conditions: Suitable For Installation Within The Specified Operating Limits
Installation Location:Industrial Environments,Subject To Model Specifications
Material
Housing: 304 Stainless Steel
Wetted Parts: Stainless Steel
Sensing Element: Sputtered Thin Film
Robust Industrial Construction.
Electrical Data
Electrical Output: 4–20 mA
Supply Voltage: 8–30 VDC
Electrical Connection: G1/4,as Listed For This Model
Signal Compatibility: Compatible With The Corresponding Industrial Control System When Correctly Specified
Installation Guide
Verify That The Operating Pressure Does Not Exceed The Transmitter Specified Range
Ensure That The Process Connection Matches The Installation Port
Install The Transmitter Securely Using The Specified Fitting
Connect The Electrical Wiring According To The Manufacturer Wiring Diagram
Check The Power Supply And Output Compatibility
Inspect The Installation For Pressure Leaks
Verify The Output Signal Before Commissioning
Approval
Manufacturer Certifications,Electrical Approvals And Compliance Details Should Be Verified Against The Official Datasheet For Model 3100B0030G01B Accessories
Setra Model 3100B0200S01Bis an Industrial OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Pressure Up To 0–200 Bar.It Uses Thin-Film Sensing Technology And is Suitable For Industrial,Hydraulic,Irrigation,Pump,Compressor And Process-Monitoring Applications.The Specified Configuration Uses 4–20 mA Output,8–30 VDC Supply And 1/4″ NPT Process Connection Technical Data
Brand: Setra Systems
Series: Model 3100
Part No.: 3100B0200S01B
Pressure Range: 0–200 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% FS
Pressure Type: Gauge/Sealed Gauge configuration as ordered
Process Connection: 1/4″ NPT Male
Electrical Connection: Industrial DIN
Enclosure: IP67
Operating Temperature: -40°C to +125°C
Compensated Temperature: -40°C to +125°C
Response Time: Approximately 1 ms
Wetted Parts: 17-4PH Stainless-Steel Diaphragm And 304 Stainless-Steel Fittings
Construction: All-Welded Stainless Steel
Weight: Approx. 35 g For Standard Model 3100 Construction
Product Features:
• High Accuracy And Fast Response • Rugged Industrial Construction • 4–20 mA Standard Analog Output • Wide DC Supply Range • IP67 Protection • Excellent Vibration Resistance • Compact OEM Design • Reliable Long-Term Operation • Suitable For High-Pressure Applications • Easy Integration With PLC And Control Systems
Field Of Application:
Hydraulic Machinery,Hydraulic Power Packs,Pumps,Booster Systems, Compressors,Irrigation Systems,Water Treatment Plants,HVAC Equipment, Refrigeration Systems,Industrial Automation,Process Control, Manufacturing Machinery and OEM Equipment
Ambient Condition:
Designed For Industrial Environments With An Operating Temperature Range Of Approximately -40°C to +125°C.IP67 Protection Helps Protect Against Dust And Water Ingress When Correctly Installed
Material:
Stainless-Steel Construction With Stainless-Steel Wetted Components, Suitable For Demanding Industrial Pressure Applications
Electrical Data:
2-Wire 4–20 mA Current Output With 8–30 VDC Supply.Connect The Transmitter According To The Specified Wiring Diagram And Maintain Correct Polarity
Installation Guide:
Install On a Compatible 1/4″ NPT Pressure Port.Use Suitable Sealing Material Where Required.Do Not Exceed The Rated Pressure Range. Connect The 4–20 mA Loop To a Suitable DC Supply And Control System. Check For Leakage And Verify The Output Signal After Installation
Approval:
Applicable Configurations Provide IP67 Protection And Relevant EMC/RoHS Compliance.Check The Product Label And Exact Datasheet For Configuration-Specific Approvals
Accessories:
Mating Connector,Cable,Pressure Fittings,Thread Adapters,24 VDC Power Supply,PLC/Display Interface And Calibration Equipment.
The Setra 3100B0050G01B Pressure Transmitteris Designed For Industrial Pressure Measurement.It is Suitable For Hydraulic Systems, Compressors,Pumps,Process Equipment And Industrial Automation Applications.Its Compact Design Supports Reliable Pressure Monitoring In Industrial Environments.
