Setra 3100T200PG1G9 is an industrial pressure transmitter designed for accurate and reliable measurement of pressure up to 200 PSI. It is suitable for industrial machinery, process control, hydraulic and pneumatic systems, compressors, pumps, OEM equipment and automation applications.
Industrial Process Control,Hydraulic Systems,Pneumatic Systems,Air compressors,Pumps,HVAC equipment,Industrial Machinery,Manufacturing plants,OEM equipment,Process Automation, instrumentation,Water Treatment,Chemical Processing,Pharmaceutical equipment,Food Processing,Packaging Machinery and General Pressure Monitoring
Ambient Condition
Install and operate within the manufacturer specified temperature, pressure and environmental limits. Protect the transmitter from excessive vibration,Shock,Moisture,Corrosive chemicals and conditions outside its rated specifications.
Material
Industrial-grade construction. Wetted and housing materials depend on the exact transmitter configuration.Verify the manufacturer Specification For compatibility with the process medium
Electrical Data
Power Supply,Output Signal And Electrical Connection Are According To the specific 3100T200PG1G9 configuration. Follow the manufacturer’s wiring diagram and verify the nameplate before electrical connection.Proper Grounding and suitable signal wiring are recommended
Installation Guide
Isolate and depressurize the process line
Install using the correct process connection and sealing method
Avoid excessive mechanical force
Connect wiring according to the manufacturer’s diagram
Apply the correct power supply
Check process and electrical connections
Slowly apply pressure and check for leakage
Verify the output signal and connect to the PLC/DCS/controller
Approval
Approval And Certification Depend On The Exact Product Configuration. Verify The Transmitter Nameplate And Official Manufacturer Documentation For Applicable Certifications Before Installation
Setra Model3100B0010G02B is a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–10 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0010G02B
Pressure Range: 0–10 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Media: Compatible Gases And Liquids,Subject To Wetted-Material Compatibility
Pressure Connection: 1/4″-18 NPT Male / Ext.
Electrical Connection: Industrial DIN
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 10 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: Industrial DIN
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–10 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements
Setra Model3100S0010G02B is a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–10 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100S0010G02B
Pressure Range: 0–10 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Media: Compatible Gases And Liquids,Subject To Wetted-Material Compatibility
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 10 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–10 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements
SETRA Model3100B0016C02B is a Compact Industrial Pressure Transmitter Designed For Accurate And Reliable Measurement Of Gauge Pressure up to 0–16 Bar.The 3100 Series Uses Sputtered Thin-Film Sensing Technology And Stainless-Steel Wetted Construction For Dependable Performance in OEM And Industrial Applications.The Transmitter Provides a Standard 4–20 mA Output And Operates From An 8–30 VDC Supply.
Technical Data
Brand: SETRA
Model: 3100B0016C02B
Pressure Range: 0–16 Bar
Pressure Type: Gauge
Output Signal: 4–20 mA
Supply Voltage: 8–30 VDC
Pressure Connection: 1/4″ NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Temperature Range: -40°F to 257°F
Sensing Technology: Sputtered Thin Film
Wetted Material: Stainless Steel
Approval: cURus
RoHS Compliant
Weight: Approximately 35 g
Media: Compatible With Suitable Liquids And Gases
Application Areas: Hydraulic Systems,Pumps,Compressors,Refrigeration,HVAC/R, irrigation Systems,Process Monitoring And Industrial Machinery.
Product Features
0–16 Bar Gauge Pressure Measurement
Stable 4–20 mA Industrial Output
Compact OEM Design
Stainless-Steel Wetted Parts
IP67 Enclosure Protection
Wide Operating Temperature Capability
Reliable Thin-Film Sensing Technology
Suitable For Space-Limited Installations
Designed for Long-Term Industrial Operation
Field Of Application
Suitable For Industrial Process Monitoring,Hydraulic Systems,Irrigation Equipment,HVAC And Compressors,Variable-Speed Pumps,Refrigeration Systems,OEM Machinery,Water Systems,Pneumatic Equipment And General Pressure Monitoring Applications.
Ambient Condition
The Transmitter is Designed For Industrial Environments With a Broad Operating Temperature Range.For Installation,Avoid Excessive Vibration, Direct Mechanical Impact,Moisture Ingress And Temperatures Outside The Specified Range.
Material
The Pressure-Sensing Wetted Components Are Stainless Steel.The Compact Construction is Designed For Industrial OEM Applications
Electrical Data
Supply: 8–30 VDC
Output: 4–20 mA
Electrical Connection: DIN 43650 Form C
Protection: IP67
Installation Guide
Install The Transmitter Using The Specified 1/4″ NPT Pressure Connection.Apply Suitable Thread Sealing Where Required. Ensure The Pressure Port is Free From Contamination.Connect The 8–30 VDC Supply and 4–20 mA Signal According to The Applicable Wiring Configuration. Do Not Exceed The Specified Pressure or Electrical Limits.
Approval
cURus approval and RoHS Compliance Are Listed For This Model.
Accessories
Compatible Pressure Fittings
Thread Adapters
Electrical Mating Connector
Cable/Connection Accessories
Pressure Isolation Accessories
Mounting And Installation Accessories
Part No.:3100B0016C02B Range: 0–16 Bar | Output: 4–20 mA | Supply: 8–30 VDC
Setra Model3100B0016G01B is a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–16 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0016G01B
Pressure Range: 0–16 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Media: Compatible Gases And Liquids,Subject To Wetted-Material Compatibility
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 20 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–16 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements.
Setra Model3100B0040G01B is a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–40 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0040G01B
Pressure Range: 0–40 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Media: Compatible Gases And Liquids,Subject To Wetted-Material Compatibility
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 20 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–40 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements
SETRA Model 3100 Is a Compact OEM Industrial Pressure Transmitter Designed For Accurate And Reliable Measurement of Gauge Pressure.Part No.3100S0007G02B is Specified For a 0 to 7 Bar Pressure Range.The Model 3100 Uses Sputtered Thin-Film Sensing Technology And Rugged Welded Stainless-Steel Construction For Demanding Industrial Applications Technical Data
Model:SETRA 3100
Part No:3100S0007G02B
Pressure Range:0 to 7 Bar
Supply:8-32 VDC
OUTPUT:4…20 MA
CONNECTION:1/4″ NPT 304 SS
Pressure Type:Gauge
Accuracy:±0.25% FS
Response Time:1 ms
Enclosure Protection:IP67
Wetted Parts:17-4PH SS Diaphragm,304 SS Fittings
Operating/Storage Temperature:-40°C to +125°C
Compensated Temperature Range:-40°C to +125°C
Long-Term Stability:±0.2% FS For Ranges Below 60 Bar
Construction:All-Welded SS
Weight:Approximately 35 g
Product Features
High Accuracy And Repeatability
Sputtered Thin-Film Sensing Technology
Compact Design,Less Than 1 Inch Diameter
Rugged SS Construction
IP67 Environmental Protection
Excellent Vibration And Shock Resistance
Reverse Wiring Protection
Fast 1 ms Response Time
Suitable for OEM And Industrial Equipment
Field of Application
Hydraulic Systems
Industrial Machinery
Booster Pump Systems
Water And Irrigation Systems
Process Equipment
Compressors
HVAC And Industrial Automation
Power Generation Equipment
Mobile And Off-Highway Machinery
Pressure Monitoring And Control Systems
Ambient Condition
The Transmitter is Designed For Operation And Storage From-40°C to +125°C.Its IP67 Enclosure Provides Protection Against Dust And Temporary Water Exposure When Correctly Installed Material
The Pressure Sensing Diaphragm is 17-4PH SS,With 304 SS Fittings.The All-Welded SS Construction Provides Durability For Industrial Environments Electrical Data
The Model 3100 Family is Available With Multiple Electrical Output Configurations,Including 4–20 mA,1–6 VDC,1–5 VDC,0.5–4.5 VDC,0–5 VDC and 0–10 VDC,Depending On The Configured Part Number.The Exact Electrical Output And Connection Should Be Verified Against The Complete Ordering Code Before Installation.For 0–7 Bar versions,Setra Specifies That 0–10 V Output is Not Available Below 7 Bar Installation Guide
Verify The Pressure Range,Output And Pressure Connection Before Installation
Install The Transmitter Using The Correct Compatible Pressure Fitting
Do Not Exceed The Rated Pressure Range
Connect The Electrical Wiring According To The Applicable Setra Wiring Diagram
Protect The Cable/Connector From Excessive Moisture,Mechanical Damage And Contamination
Check For Leakage And Verify The Output Signal After Installation
Approval
Model 3100 is CE And UL Approved and RoHS Compliant,With IP67 protection Accessories
Setra Model3100B0020G01Bis a High-Pressure OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Hydraulic And Industrial Pressure.It Uses Sputtered Thin-Film Sensing Technology With Rugged Stainless-Steel Construction And IP67 Environmental Protection.The 0–20 Bar Range Makes It Suitable For Demanding High-Pressure Applications Technical Data
Model: 3100B0020G01B
Pressure Range: 0–20 Bar
Output: 4–20 mA
Supply Voltage: 8–30 VDC
Accuracy: ±0.25% Full Scale
Pressure Connection: G 1/4-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Rating: IP67
Operating/Storage Temperature: -40°C to +125°C
Response Time: Approx. 1 ms
Wetted Parts: Stainless Steel
Construction: All-welded stainless steel
Approval: cURus
RoHS Compliant
Weight: 35G
Product Features
High-Pressure Measurement Up to 20 Bar
±0.25% FS Accuracy
Sputtered Thin-Film Sensing Element
Rugged Stainless-Steel Construction
IP67 Protection Against Moisture And Dust
Fast Response Time
Wide Operating Temperature Range
Reverse Wiring Protection
Suitable For OEM And Industrial Equipment
Designed For High Shock And Vibration Environments
Field Of Application
Hydraulic Pressure Systems
Hydraulic Machinery
Industrial OEM Equipment
Pumps and Variable-Speed Pumps
Compressors
Refrigeration Systems
Industrial Machinery
Irrigation Pressure Systems
Process Control Equipment
High-Pressure Fluid Systems
HVAC/R Equipment
Ambient Condition
The Transmitter is Designed For Demanding Industrial Environments. Operating And Storage Temperature is Approximately -40°C to +125°C. IP67 Enclosure Protection Provides Resistance Against Dust And Temporary Water Exposure Material
The Model 3100 Uses An All-Welded Stainless-Steel Construction.Wetted Components Include Stainless-Steel Materials Suitable For Compatible Industrial Pressure Media Electrical Data
Output: 4–20 mA
Supply: 8–30 VDC
Circuit: 2-wire
Electrical Connection: DIN 43650 Form C
Reverse Wiring Protection Is Provided
Installation Guide
Install The Transmitter On a Compatible Pressure Port Using The Correct Sealing Method And Suitable Tools.Ensure That The Pressure Applied Remains Within The Rated 0–20 Bar Range.Connect The Power Supply And Signal Wiring According To The Specified Electrical Configuration.For Outdoor Or Electrically Noisy Installations,Use Appropriate Shielded Wiring And Grounding Practices.Avoid Excessive Mechanical Stress On The Transmitter And Wiring Approval
cURus Approved And RoHS Compliant.Always Verify The Exact Certification Requirements For The Intended Installation Before Commissioning Accessories
Compatible Accessories May Include Pressure Fittings,Sealing Components, Electrical Connectors,Cables,Mounting Hardware and Signal/PLC Interface Equipment.Select Accessories According To The Actual Pressure Connection,Electrical Connection And Application Requirements
The Setra 3100B0070G02B Pressure Transmitter is Designed For Industrial Pressure Measurement And Monitoring Applications.It Converts Applied Pressure Into An Electrical Signal For Use In Automation,Process Control And Monitoring Systems.Its Compact Design Makes It Suitable For Installation In Industrial Equipment And Machinery Technical Data
Brand: Setra Systems
Model: 3100B0070G02B
Product Type: Pressure Transmitter
Pressure Range: 0–70 Bar
Supply Voltage: 8–30 VDC
Pressure Connection: 1/4″-18 NPT Male
Electrical Connection: DIN 43650 Form C
Enclosure Protection: IP67
Operating Temperature: −40°C to +125°C
Wetted Material: Stainless Steel
Weight: Approximately 35 g
Output Signal: 4–20 mA
Accuracy: ±0.25% FS
Product Features
Reliable Industrial Pressure Monitoring
Compact And Durable Construction
Designed For Continuous Pressure Measurement
Suitable For Industrial Automation Systems
Easy Integration With Compatible Control Equipment
Suitable For Machinery And Process Monitoring
0–70 Bar Pressure Measurement Range
Field of Application
Industrial Process Control
Hydraulic Systems
Pneumatic Equipment
Industrial Compressors
Pump And Motor Systems
Water Treatment Plants
HVAC Systems
Manufacturing Machinery
Pressure Monitoring Systems
Industrial Automation
Ambient Conditions
Operating Temperature: Refer To The Exact Model Datasheet
Storage Temperature: Refer To The Manufacturer Specifications
Environmental Conditions: Suitable For Installation Within The Specified Operating Limits
Installation Location:Industrial Environments,Subject To Model Specifications
Material
Housing: 304 Stainless Steel
Wetted Parts: Stainless Steel
Sensing Element: Sputtered Thin Film
Robust Industrial Construction.
Electrical Data
Electrical Output: 4–20 mA
Supply Voltage: 8–30 VDC
Electrical Connection: G1/4,as Listed For This Model
Signal Compatibility: Compatible With The Corresponding Industrial Control System When Correctly Specified
Installation Guide
Verify That The Operating Pressure Does Not Exceed The Transmitter Specified Range
Ensure That The Process Connection Matches The Installation Port
Install The Transmitter Securely Using The Specified Fitting
Connect The Electrical Wiring According To The Manufacturer Wiring Diagram
Check The Power Supply And Output Compatibility
Inspect The Installation For Pressure Leaks
Verify The Output Signal Before Commissioning
Approval
Manufacturer Certifications,Electrical Approvals And Compliance Details Should Be Verified Against The Official Datasheet For Model 3100B0070G02B Accessories
The Setra 3100B0030G01B Pressure Transmitter is Designed For Industrial Pressure Measurement And Monitoring Applications.It Converts Applied Pressure Into An Electrical Signal For Use In Automation,Process Control And Monitoring Systems.Its Compact Design Makes It Suitable For Installation In Industrial Equipment And Machinery Technical Data
Brand: Setra Systems
Model: 3100B0030G01B
Product Type: Pressure Transmitter
Pressure Range: 0–30 Bar
Supply Voltage: 8–30 VDC
Pressure Connection: G1/4
Electrical Connection: DIN 43650 Form C
Enclosure Protection: IP67
Operating Temperature: −40°C to +125°C
Wetted Material: Stainless Steel
Weight: Approximately 35 g
Output Signal: 4–20 mA
Accuracy: ±0.25% FS
Product Features
Reliable Industrial Pressure Monitoring
Compact And Durable Construction
Designed For Continuous Pressure Measurement
Suitable For Industrial Automation Systems
Easy Integration With Compatible Control Equipment
Suitable For Machinery And Process Monitoring
0–30 Bar Pressure Measurement Range
Field of Application
Industrial Process Control
Hydraulic Systems
Pneumatic Equipment
Industrial Compressors
Pump And Motor Systems
Water Treatment Plants
HVAC Systems
Manufacturing Machinery
Pressure Monitoring Systems
Industrial Automation
Ambient Conditions
Operating Temperature: Refer To The Exact Model Datasheet
Storage Temperature: Refer To The Manufacturer Specifications
Environmental Conditions: Suitable For Installation Within The Specified Operating Limits
Installation Location:Industrial Environments,Subject To Model Specifications
Material
Housing: 304 Stainless Steel
Wetted Parts: Stainless Steel
Sensing Element: Sputtered Thin Film
Robust Industrial Construction.
Electrical Data
Electrical Output: 4–20 mA
Supply Voltage: 8–30 VDC
Electrical Connection: G1/4,as Listed For This Model
Signal Compatibility: Compatible With The Corresponding Industrial Control System When Correctly Specified
Installation Guide
Verify That The Operating Pressure Does Not Exceed The Transmitter Specified Range
Ensure That The Process Connection Matches The Installation Port
Install The Transmitter Securely Using The Specified Fitting
Connect The Electrical Wiring According To The Manufacturer Wiring Diagram
Check The Power Supply And Output Compatibility
Inspect The Installation For Pressure Leaks
Verify The Output Signal Before Commissioning
Approval
Manufacturer Certifications,Electrical Approvals And Compliance Details Should Be Verified Against The Official Datasheet For Model 3100B0030G01B Accessories
